OP-809B1
● High attack frequency.
● Low counteraction.
● One hand operation forward and reverse
● Reverse button has self locking function
● Oil-in-the-front cap design for extended long performance life
● Rear exhaust with muffler
● Hook design can be used for spring balancer. More efficiency and more safe for the workers.
Application:
Especially in heavy-productive industries
(rattan, carpentry, electric, motor, aluminum, and hardware).
● Low counteraction.
● One hand operation forward and reverse
● Reverse button has self locking function
● Oil-in-the-front cap design for extended long performance life
● Rear exhaust with muffler
● Hook design can be used for spring balancer. More efficiency and more safe for the workers.
Application:
Especially in heavy-productive industries
(rattan, carpentry, electric, motor, aluminum, and hardware).
SPECIFICATION(air pressure at 90 psi、6.2bar、6.3kg/cm2)
Packing :
Carton : 10 pcs / N.W. : 11.5 kg / G.W : 13.81 kg / Cuft : 1.4 "
| MODEL | Anvil Size |
Bolt Size Capacity |
Working Torque |
MAX. Torque |
Free Speed |
Air Consumption |
Overall Length |
Air Inlet |
Net Weight |
Sound Level |
|||||
| mm | Nm | ft-lb | Nm | ft-lb | rpm | l/min | cfm | mm | inch | P.T | Kg | lb | dB(A) | ||
| OP-809B1 | 3/8" | M10 | 80 | 59 | 130 | 96 | 8000 | 184 | 6.5 | 230 | 9.06 | 1/4 | 1.2 | 2.65 | 80 |
Packing :
Carton : 10 pcs / N.W. : 11.5 kg / G.W : 13.81 kg / Cuft : 1.4 "
