(1) High speed.
(2) Low vibration.
Application: Especially in heavy-productive industries rattan, motor.
Specifications: OP-601L: Low rotational speed, Side exhaust
| MODEL | Screw Size Capacity | Working Torque |
MAX. Torque |
Free | Air Consumption |
Overall Length |
Air Inlet |
Net Weight |
Sound Level |
|||||
| Speed | ||||||||||||||
| mm |
Nm | ft-lb | Nm | ft-lb | rpm | l/min | cfm | mm | inch | P.T | Kg | lb | dB(A) | |
| OP-601L | 4~5 | 20 | 15 | 50 | 37 | 2700 | 184 | 6.5 | 185 | 7.28 | 1/4 | 1.13 | 2.49 | 82 |
