OP-601B

OP-601B
Share to:

Specifications: OP-601B: Side exhaust, Low Rotational Speed

(1) High speed.
(2) Low vibration.
Application: Especially in heavy-productive industries rattan, motor.

MODEL Bolt Size
Capacity
Working
Torque
MAX.
Torque
Free
Speed
Air
Consumption
Overall
Length
Air
Inlet
Net
Weight
Sound
Level
mm
Nm ft-lb Nm ft-lb rpm l/min cfm mm
inch P.T
kg lb dB(A)
OP-601B M10 45 33 50 37 2700 170  6 185 7.28 1/4 1.13 2.49 82
